Speichermedium Installierte Speichertreiber Nein Anzahl der unterstützten Speicherlaufwerke 5 Typ des installierten ...
Speichermedium | |
Installierte Speichertreiber | Nein |
Anzahl der unterstützten Speicherlaufwerke | 5 |
Typ des installierten Speicherlaufwerks | Nein |
Unterstützte Speicherlaufwerke | HDD & SSD |
RAID-Unterstützung | Ja |
Unterstützte Speicherlaufwerk-Schnittstellen | SATA |
unterstützte Speicherlaufwerksgrößen | 2.5,3.5" |
Maximal unterstützte Speicherkapazität | 80 TB |
RAID Level | 0, 1, 5, 6, 10, JBOD |
Online-RAID-Migration | Ja |
Im laufenden Betrieb wechselbare Gehäuseschächte | Ja |
Unterstützte Dateisysteme | BTRFS, FAT32, HFS+, NTFS, ext3, ext4 |
Prozessor | |
Prozessorfamilie | Intel® Celeron® |
Prozessorhersteller | Intel |
Prozessor | J3355 |
Prozessor-Taktfrequenz | 2 GHz |
Prozessor Boost-Frequenz | 2,5 GHz |
Anzahl Prozessorkerne | 2 |
Prozessor-Threads | 2 |
Prozessor-Cache | 2 MB |
CPU Konfiguration (max) | 1 |
PCI Express Konfigurationen | 1x2+2x1, 4x1 |
PCI-Express-Slots-Version | 2.0 |
Prozessor Cache Typ | Smart Cache |
Prozessor-Code | SR2Z8 |
Prozessor Codename | Apollo Lake |
Prozessor Lithografie | 14 nm |
Prozessorbetriebsmodi | 64-Bit |
Prozessor-Paketgröße | 24 x 31 mm |
Prozessorsockel | BGA 1296 |
Stepping | B1 |
Systembus-Rate | 5 GT/s |
Tjunction | 105 °C |
Thermal Design Power (TDP) | 10 W |
On-Board Grafikadaptermodell | Intel® HD Graphics 500 |
Maximaler interner Speicher, vom Prozessor unterstützt | 8 GB |
Konfliktloser-Prozessor | Ja |
Speicher | |
Speicherkapazität | 2 GB |
Maximum unterstützte RAM | 10 GB |
Speicherkartensteckplätze | 1 |
Netzwerk | |
Ethernet/LAN | Ja |
Ethernet LAN Datentransferraten | 1000 Mbit/s |
iSCSI-Unterstützung | Ja |
Unterstützte Netzwerkprotokolle | CIFS/SAMBA, NFS, FTP, TFTP, HTTPS, SSH, iSCSI, SNMP, SMTP |
Link Aggregation | Ja |
Dynamisches DNS (DDNS) | Ja |
Anschlüsse und Schnittstellen | |
Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 2 |
USB Anschluss | Ja |
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 2 |
Anzahl HDMI-Anschlüsse | 1 |
Grafik | |
On-Board Grafikadapter Basisfrequenz | 250 MHz |
On-Board Grafikadapter Burstfrequenz | 700 MHz |
Maximaler integrierter Grafik-Adapterspeicher | 8 GB |
Anzahl an unterstützen Displays (On-Board-Grafik) | 3 |
Design | |
Gehäusetyp | Desktop |
Kühlung | Aktiv |
Produktfarbe | Grau |
Anzahl Lüfter | 2 Lüfter |
Lüfterdurchmesser | 8 cm |
Durchmesser Lüfter 2 | 8 cm |
LED-Anzeigen | HDD, LAN, Leistung |
Eingebautes Display | Nein |
Leistungen | |
Typ | NAS |
Geräteklasse | Kleines & Mittleres Unternehmen |
Backup-Funktion | Ja |
Backup-Funktionen | Cloud, USB-Stick |
Mehrsprachige Unterstützung | Ja |
Zahl der Benutzer | 512 Benutzer |
Geräuschpegel | 19,8 dB |
Drittunterstützung | Ja |
Schnappschuss | Ja |
Management-Protokolle | SNMP |
Web-basiertes Management | Ja |
Unterstützte Sicherheitsalgorithmen | AES, HTTPS, SNMP, SSH |
Zugriffkontrollliste | Ja |
Ein-/Ausschalter | Ja |
Unterstützter Browser | Google Chrome 48, Microsoft Internet Explorer 9, Mozilla Firefox 30,Apple Safari 4.5 |
Systemprotokoll | Ja |
Hot Spare | Ja |
S.M.A.R.T. Unterstützung | Ja |
Gemeinsamer Ordner | 256 |
Universal Plug and Play (UPnP) | Ja |
Software | |
Unterstützt Windows-Betriebssysteme | Ja |
Unterstützte Linux-Betriebssysteme | Ja |
Unterstützt Mac-Betriebssysteme | Ja |
Energie | |
Platzierung der Stromversorgung | Extern |
Kapazität der Stromversorgungseinheit | 90 W |
Anzahl von Stromversorgungseinheiten | 1 |
Stromverbrauch (Standardbetrieb) | 56,6 W |
AC Eingangsspannung | 100-240 V |
AC Eingangsfrequenz | 50 - 60 Hz |
Ausgangsspannung | 12 V |
Gewicht und Abmessungen | |
Breite | 225 mm |
Tiefe | 136 mm |
Höhe | 227 mm |
Gewicht | 2,33 kg |
Verpackungsbreite | 275 mm |
Verpackungstiefe | 186 mm |
Verpackungshöhe | 300 mm |
Paketgewicht | 3,63 kg |
Lieferumfang | |
Externes Netzteil | Ja |
Mitgelieferte Kabel | AC, LAN (RJ-45) |
Technische Details | |
Nachhaltigkeitszertifikate | RoHS |
Prozessor Besonderheiten | |
Eingebettete Optionen verfügbar | Ja |
Verbesserte Intel SpeedStep Technologie | Ja |
Execute Disable Bit | Ja |
Leerlauf Zustände | Ja |
Intel® 64 | Ja |
Intel® Clear Video Technologie | Ja |
Intel® Enhanced Halt State | Ja |
Intel® Identity Protection Technologieversion | 1,00 |
Intel® Rapid-Storage-Technik | Nein |
Intel® Secure Boot | Ja |
Intel® Secure Boot Technologieversion | 1,00 |
Intel® Secure Key Technologieversion | 1,00 |
Intel® Small Business Advantage (SBA) Version | 0,00 |
Intel® Smart-Connect-Technik | Nein |
Intel® Smart Connect Technologieversion | 0,00 |
Intel® Smart Response Technologieversion | 0,00 |
Intel Stable Image Platform Program (SIPP) | Nein |
Intel® Stable Image Platform Program (SIPP) Version | 0,00 |
Intel® Trusted-Execution-Technik | Nein |
Intel® Virtualization Technologie (VT-X) | Ja |
Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
Intel® VT-x mit Extended Page Tables (EPT) | Ja |
Intel® AES New Instructions (Intel® AES-NI) | Ja |
Intel® Anti-Theft Technologie (Intel® AT) | Nein |
Intel® Clear Video HD Technology für (Intel® CVT HD) | Ja |
Intel® Clear Video Technology für Mobile Internet Devices (Intel® CVT for MID) | Ja |
Intel HD-Audio-Technik | Ja |
Intel® Hyper-Threading-Technik (Intel® HT Technology) | Nein |
Intel® Identity-Protection-Technologie (Intel® IPT) | Ja |
Intel® Insider™ | Nein |
Intel® InTru™ 3D Technologie | Nein |
Intel® OS Guard | Nein |
Intel® Quick-Sync-Video-Technik | Ja |
Intel® Sicherer Schlüssel | Ja |
Intel® Small-Business-Advantage (Intel® SBA) | Nein |
Intel® Smart-Response-Technologie | Nein |
Intel® Turbo-Boost-Technologie | Nein |
Intel® Wireless-Display (Intel® WiDi) | Nein |
Maximale Anzahl der PCI-Express-Lanes | 6 |
Anzahl der Rechenwerke | 12 |
Thermal-Überwachungstechnologien | Ja |
UART | Ja |
Speichertypen, vom Prozessor unterstützt | DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM |
Betriebsbedingungen | |
Betriebstemperatur | 5 - 40 °C |
Relative Luftfeuchtigkeit in Betrieb | 5 - 95% |
Temperaturbereich bei Lagerung | 20 - 60 °C |
Zertifikate | |
Zertifizierung | FCC, CE, CCC, KC |
Sonstige Funktionen | |
Digital Living Network Alliance (DLNA) zertifiziert | Ja |
ARK Prozessorerkennung | 95597 |
