| Hersteller |
Netgear |
| Typ |
Standalone, Rackmount (via Montagewinkel) |
| Netzwerkanschlüsse |
40x RJ-45 (Rückseite), 8x SFP+ (Rückseite) |
| Geschwindigkeiten |
40x RJ-45 (10/?100/?1000Base-T), 8x SFP+ (1G/?10Gb/?s) |
| PoE |
40x RJ-45 PoE+ (40x 30W), gesamt: 960W |
| Backplane |
240Gb/?s, 178.56Mp/?s, 12KB Jumboframes, 32Mb Paketpuffer, 16K Mac-Adressen |
| Offiziell unterstützte Standards |
802.1AB, 802.1AS, 802.1AX, 802.1BA, 802.1D, 802.1Q, 802.1Qat, 802.1Qat-2010, 802.1Qav, 802.1Qav-2009, 802.1S, 802.1w, 802.1X, 802.1AB, 802.1ak, 802.1p, 802.1s, 802.1v, 802.1w, 802.1X, 802.3, 802.3ad, 802.3ab, 802.3ac, 802.3ad, 802.3ae, 802.3af, 802.3aq, 802.3at, 802.3az, 802.3bz, 802.3u, 802.3x, IGMPv3 |
| Konfiguration |
Webinterface, Konsole, seriell (USB-A 2.0), seriell (USB-C 2.0, RJ-45, Rückseite), Netzwerk (RJ-45, dediziert, 10/?100/?1000Base-T, Rückseite) |
| Kühlung |
aktiv, 4x Lüfter (40mm, links, links nach rechts) |
| Abmessungen (BxHxT) |
440x43.2x400mm, 1HE |
| Gewicht |
6.31kg |
| Farbe |
anthrazit |
| Besonderheiten |
Metallgehäuse, abnehmbare Montagewinkel, Firmwareupdates möglich, IPTV |
